View In:   ArcGIS Online Map Viewer

Name: Building Footprints

Display Field: Bldg_Name

Type: Feature Layer

Geometry Type: esriGeometryPolygon

Description: Woolpert completed a semi-automated method for building generation utilizing new countywide 2009 LiDAR data and existing 2005-2008 orthoimagery. Buildings over 100 square feet were generated and run through a QC process. The final building polygons were developed for the entire ±709-square mile county area. The dataset has had all but those footprints near or within the City of Ann Arbor and contains an average building height. Updates are currently done with new construction plans and then verified using the newest aerial imagery.

Copyright Text: Woolpert and City of Ann Arbor Community Services

Default Visibility: true

MaxRecordCount: 2000

Supported Query Formats: JSON, geoJSON, PBF

Min Scale: 0.0

Max Scale: 0.0

Supports Advanced Queries: true

Supports Statistics: true

Can Scale Symbols: false

Use Standardized Queries: true

Supports ValidateSQL: true

Supports Calculate: true

Supports Datum Transformation: true

Extent:

XMin: 1.3276910502544079E7
YMin: 262025.48525194824
XMax: 1.331429638577741E7
YMax: 300814.0740132034
Spatial Reference: 2253  (2253)  LatestVCSWkid(0)

Drawing Info:

Renderer:
Simple Renderer:
Symbol:
Style: esriSFSSolid
Color: [252, 207, 225, 255]
Outline:
Style: esriSLSSolid
Color: [110, 110, 110, 255]
Width: 0
Label: N/A
Description: N/A
Transparency: 0
Labeling Info:

Advanced Query Capabilities:

Supports Statistics: true
Supports OrderBy: true
Supports Distinct: true
Supports Pagination: true
Supports TrueCurve: true
Supports Returning Query Extent: true
Supports Query With Distance: true
Supports Sql Expression: true
Supports Query With ResultType: true
Supports Returning Geometry Centroid: false
Supports Binning LOD: false
Supports Query With LOD Spatial Reference: false

HasZ: false

HasM: false

Has Attachments: false

HTML Popup Type: esriServerHTMLPopupTypeAsHTMLText

Type ID Field:

Fields:

• OBJECTID ( type: esriFieldTypeOID, alias: OBJECTID, editable: false, nullable: false, defaultValue: null, modelName: OBJECTID )
• ABG_BLD_HG ( type: esriFieldTypeDouble, alias: ABG_BLD_HG, editable: true, nullable: true, defaultValue: null, modelName: ABG_BLD_HG )
• AVG_DEM ( type: esriFieldTypeDouble, alias: AVG_DEM, editable: true, nullable: true, defaultValue: null, modelName: AVG_DEM )
• Struc_Type ( type: esriFieldTypeString, alias: Struc_Type, editable: true, nullable: true, length: 20, defaultValue: null, modelName: Struc_Type )
• Bldg_Name ( type: esriFieldTypeString, alias: Bldg_Name, editable: true, nullable: true, length: 50, defaultValue: null, modelName: Bldg_Name )
• Owned_By ( type: esriFieldTypeString, alias: Owned_By, editable: true, nullable: true, length: 20, defaultValue: null, modelName: Owned_By )
• Updated ( type: esriFieldTypeString, alias: Updated, editable: true, nullable: true, length: 1, defaultValue: null, modelName: Updated )
• FacilityID ( type: esriFieldTypeString, alias: FacilityID, editable: true, nullable: true, length: 20, defaultValue: null, modelName: FacilityID )
• PackedPin ( type: esriFieldTypeString, alias: PackedPin, editable: true, nullable: true, length: 20, defaultValue: null, modelName: PackedPin )
• STORIES ( type: esriFieldTypeDouble, alias: STORIES, editable: true, nullable: true, defaultValue: null, modelName: STORIES )
• GlobalID ( type: esriFieldTypeGlobalID, alias: GlobalID, editable: false, nullable: false, length: 38, defaultValue: null, modelName: GlobalID )
• created_user ( type: esriFieldTypeString, alias: created_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: created_user )
• created_date ( type: esriFieldTypeDate, alias: created_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: created_date )
• last_edited_user ( type: esriFieldTypeString, alias: last_edited_user, editable: false, nullable: true, length: 255, defaultValue: null, modelName: last_edited_user )
• last_edited_date ( type: esriFieldTypeDate, alias: last_edited_date, editable: false, nullable: true, length: 8, defaultValue: null, modelName: last_edited_date )
• Shape__Length ( type: esriFieldTypeDouble, alias: Shape_Length, editable: false, nullable: true, defaultValue: null, modelName: Shape_Length )
• Shape__Area ( type: esriFieldTypeDouble, alias: Shape_Area, editable: false, nullable: true, defaultValue: null, modelName: Shape_Area )

Templates:

• Name: Building Footprints
  Description:
  Prototype:
  STORIES: null
  ABG_BLD_HG: null
  AVG_DEM: null
  Struc_Type: null
  Bldg_Name: null
  Owned_By: null
  Updated: null
  FacilityID: null
  PackedPin: null

  Drawing Tool: esriFeatureEditToolPolygon

Capabilities: Query,Extract

Sync Can Return Changes: false

Is Data Versioned: false

Supports Rollback On Failure: true

Supports ApplyEdits With Global Ids: false

Edit Fields Info:

• Creation Date Field: created_date
• Creator Field: created_user
• Edit Date Field: last_edited_date
• Editor Field: last_edited_user

Supports Query With Historic Moment: false

Supports Coordinates Quantization: true

Supported Operations:   Query   Query Attachments   Query Analytic   Calculate   Validate SQL   Generate Renderer   Return Updates   Iteminfo   Thumbnail   Metadata
